商品規格

硬體規格

項目 規格
CPU 型號 Intel Celeron N5105
處理器架構 x64 64-bit
處理器時脈 Quad-Core 2.0GHz (burst up 2.90 GHz)
記憶體大小 4GB SO-DIMM DDR4
預先安裝記憶體模組 4GB (1 x 4GB)
記憶體插槽總數 2
記憶體可擴充至 16GB (2 x 8GB)
記憶體 Support mixed capacity
快閃記憶體 8GB eMMC
硬碟槽數量 4
M.2 硬碟槽 4
相容硬碟類型 3.5" SATA HDD；2.5" SATA HDD；2.5" SATA SSD；M.2 2280 NVMe
M.2 PCIe 介面 PCIe 3.0 x1
安裝擴充裝置之最大硬碟槽數量 12
搭配擴充裝置之最大淨總儲存容量 240 TB (20 TB HDD X 12, Capacity may vary by RAID types)
硬碟熱插拔支援 支援
外接硬碟介面 2 x USB 3.2 Gen 2 (10Gbps) Type-A；1 x USB 2.0 Type-A
網路 2 x 5 Gigabit Ethernet (5G/2.5G/1G/100M)
PCIe 擴充插槽 1 x for optional expansion 10 GbE card
多媒體輸出 1 x HDMI 2.0b
系統風扇 1 x 120mm
電源供應器 / 變壓器 90W x1
輸入電壓 100V to 240V AC
認證機構 FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC, UKCA
產品保固 3 Years
電消耗功率 35 W (Operation)；17.3 W (Disk Hibernation)；0.88 W (Sleep Mode)
噪音值 17.6dB (HDD idle)
作業溫度 0°C~40°C (32°F~104°F)
儲存溫度 -20°C~70°C (-4°F~158°F)
相對溼度 5% to 95% RH
大小 185.5(H) x 170(W) x 230(D) mm
重量 2.94 kg / 6.48 lb

軟體功能

項目 規格
作業系統 ADM 4.1 Onwards；Supports Online Firmware Updates
支援的用戶端類型 Windows XP, Vista, 7, 8, 10, 11, Server 2003, Server 2008, Server 2012, Server 2016, Server 2019, Server 2022；mac OS 10.6 Onwards；UNIX, Linux, and BSD
語系 Deutsch, English, Français, Italiano, Nederlands, Русский, 日本語, 한글, 简体中文, 繁體中文, Česká, Polski, Svenska, Dansk, Norsk, Suomi, Português, Türkçe, Español, Magyar, ภาษาไทย
支援的瀏覽器 Firefox；Chrome；Safari；Microsoft Edge
網路通訊協定 CIFS / SMB, SMB 2.0 / 3.0, AFP, NFS, FTP (Unicode Supported), TFTP, WebDAV, Rsync, SSH, SFTP, iSCSI/IP-SAN, HTTP, HTTPS, Proxy, SNMP, Syslog
連接和傳輸 TCP/IP (IPv4 & IPv6)；Link Aggregation: Supports 802.3ad and Six Other Modes for Load Balancing and/or Network Failover；SMB Multichannel；Jumbo Frame (MTU)；VLAN；EZ Connect；Wireless Network；DDNS and EZ-Router；Supports Wake-on-LAN (WOL)；Supports Wake-on-WAN (WOW)
檔案系統 Internal Disk: EXT4, Btrfs；External Disk: FAT32, NTFS, EXT3, EXT4, HFS+, exFAT, Btrfs
檔案管理 Web-based File Management；ISO File Mounting；Share Links；Task Monitor；Browse Files on Local PC；Thumbnail Previews；Data Access via External Optical Drive；Supports video playback
網路資源回收筒 Share folder-based；Maintains original directory structure and file permission；One-click restore；Supports scheduled emptying；Filtering rules: File size, File extension；Deletion Settings: File size, File date

RAID

項目 規格
支援的 RAID 種類 Single；JBOD；RAID 0；RAID 1；RAID 5；RAID 6；RAID 10
RAID 組態遷移 Single to RAID 1；Single to RAID 5；Single to RAID 6；Single to RAID 10；RAID 1 to RAID 5；RAID 1 to RAID 6；RAID 1 to RAID 10；RAID 5 to RAID 6
完整更換硬碟擴充容量 RAID 1；RAID 5；RAID 6；RAID 10
增加硬碟擴充容量 RAID 5
RAID 備用硬碟 RAID 1；RAID 5

MyArchive

項目 規格
Hot swappable design Enables easy transfer or exchange of high amounts of data
Drive Bay Works on any empty bay on an ASUSTOR NAS
File system support EXT4, NTFS, HFS+, Btrfs and exFAT
AES 256-bit encryption EXT4 and Btrfs
Btrfs snapshots Supports
USB key decryption Supports

iSCSI/IP-SAN

項目 規格
Maximum Targets 256
Maximum LUNs 256
Maximum Snapshot Versions of a Single LUN 256
Target Masking 支援
LUN Mapping 支援
ISO File Mounting 支援
MPIO 支援
Persistent (SCSI-3) Reservations 支援

硬碟管理

Scheduled Bad Block Scans
Scheduled S.M.A.R.T Scans

存取控制

Maximum Number of Users: 4096
Maximum Number of Groups: 512
Maximum Number of Shared Folders: 512
Maximum Number of Concurrent Connections: 512
Supports Windows Active Directory
Supports Windows Active Directory / LDAP

ACL

Provides both Windows ACL and Linux ACL permission configuration methods
Can enable Windows ACL for specific shared folders
Comprehensive support for Windows’ 13 types of advanced permission settings
Can view Windows ACL permission settings from within ADM
Supports local users and groups
Exclusive permission reset function allows users to quickly restore default permissions

SSD Cache

SSD-like performance with traditional hard drives
Supports read-only access and read-write cache mode

系統管理

Log Type: System Log, Connection Log, File Access Log
Real-time Online User Monitor
Real-time System Monitor
User Quota
Virtual Drive (ISO Mounting, Maximum 16)
UPS Support

資料安全

AES 256-Bit Encryption
Firewall: Prevent Unauthorized Access
Alert Notifications: E-mail, SMS
Encrypted Connections: HTTPS, FTP over SSL/TLS, SSH, SFTP, Rsync over SSH
Built-in Hardware Encryption Engine
RAID Scrubbing

網路防護

Auto black list
Trusted list
Black/White list
Supports IP/IP range/geolocation

備份方案

Rsync (Remote Sync) Backup
Cloud Backup
FTP Backup
External Backup
One Touch Backup
EZ Sync
SMB Backup

快照

Btrfs Snapshots
256 Snapshots
iSCSI LUNs

ASUSTOR Hightlight

System Migration
EZ Connect
Dr. ASUSTOR
2-way Backup
Task Monitor

節能環保設計

System Automatically Enters Sleep Mode (Schedule S3)
Auto-Standby for Both Internal and External Disks
Auto Fan Control
LED Night Mode
Power Schedule: On, Off, Restart, and Sleep

節能管理

Configurable Disk Hibernation and Sleep Mode Wait Time
Configurable Time Period for Sleep Mode Activation
Automatic Sleep

功能 Apps

Antivirus (ClamAV)
ASUSTOR Portal (HDMI Local Output)
VirtualBox
Download Center
Cloud Backup Center
DataSync Center
FTP Explorer
LooksGood
Mail Server
Photo Gallery 3
Surveillance Center
SoundsGood
Takeasy
UPnP Media Server
VPN Client
VPN Server
RADIUS Server
SNMP Server
Syslog Server

官方效能

項目 讀取 寫入
5GbE x2 SMB Multichannel - Windows File Transfer (10GB file x1) 1146 MB/s 536 MB/s
5GbE x2 SMB Multichannel - Windows File Sequential Transfer (512KB) 1179 MB/s 1111 MB/s
Aggregated 5GbE - SMB Sequential (512KB) 1151 MB/s 1135 MB/s
Aggregated 5GbE - iSCSI Sequential (512KB) 1110 MB/s 1124 MB/s
Aggregated 5GbE SMB - Windows File Transfer (100GB file x1) 1126 MB/s 566 MB/s
Aggregated 5GbE iSCSI - Windows File Transfer (100GB file x1) 956 MB/s 555 MB/s
5GbE - SMB Sequential (512KB) 591 MB/s 589 MB/s
5GbE - iSCSI Sequential (512KB) 590 MB/s 583 MB/s
