商品規格

198041【SINYA C4U尊榮服務 (SINYA品牌桌機專屬/Windows終生免費重灌)】
============================================
201481【darkFlash DRX70 黑 玻璃透側機殼 (ATX/Type-C/內建風扇前3後1/磁吸面板/內附顯卡支架/ARGB燈光/顯卡350mm/塔散180mm)】
◆顏色：黑 / 白

◆尺寸：39.6 x 23 x 46.2 cm

◆CPU散熱器高度：18 cm 以內

◆顯卡長度：最長支援 35 cm

◆支援水冷散熱排：240 (上)

◆硬碟空間：3.5" x2 / 2.5" x1

◆內附風扇：12cm ARGB x3 (前) /12cm ARGB x1 (後)

◆風扇支援：12cm or 14cm x3 (前) / 12cm x2 or 14cm x2 (上) / 12cm or 14cm x1 (後) / 12cm x2 (電源罩)

◆前I/O：U3*1 + U2 *1 + TYPE-C *1============================================
205758【【獨家】微星 PRO B650-A WIFI (ATX/1H1P/Realtek 2.5Gb/WiFi 6E+BT 5.3/註冊五年保) 14+2+1相供電】
Chipset AMD B650
CPU Supports AMD Ryzen™ 9000/ 8000/ 7000 Series Desktop Processors
Socket AM5
Memory 4x DDR5, Maximum Memory Capacity 256GB
Memory Support DDR5 7600+(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 7600+ MHz
• 1DPC 2R Max speed up to 6400+ MHz
• 2DPC 1R Max speed up to 6400+ MHz
• 2DPC 2R Max speed up to 5400+ MHz

Supports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports AMD EXPO
Onboard Graphics 1x HDMI™
Support HDMITM 2.1 with HDR, maximum resolution of 4K 60Hz*
1x DisplayPort
Support DP 1.4 port with HBR3, maximum resolution of 8K 60Hz*
*Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
Slot 2x PCI-E x16 slot (Qty)
• Supports x16/x2 (For Ryzen™ 9000/ 7000 Series processors)
• Supports x8/x2 (For Ryzen™ 8700/ 8600/ 8400 Series processors)
• Supports x4/x2 (For Ryzen™ 8500/ 8300 Series processors)
1x PCI-E x1 slot (Qty)
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 4.0 supports up to x2 (From Chipset)
PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset)
* PCI_E2 & M2_3 share the bandwidth. PCI_E2 will run at x2 speed and M2_3 will run at x2 speed when installing devices in both slots.
Audio Realtek® ALC4080 Codec
7.1-Channel High Performance Audio
Supports S/PDIF output
Supports up to 32-Bit/384 kHz playback on front panel
Storage 3x M.2 (Qty)
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 22110/2280 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_3 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
6x SATA 6G (Qty)
* The M2_2 slot will be unavailable when using Ryzen™ 8500/ 8300 Series processor
** M2_3 & PCI_E2 share the bandwidth. M2_3 will run at x2 speed and PCI_E2 will run at x2 speed when installing devices in both slots.
RAID Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices*
Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices
* SATA_A1 & SATA_A2 do not support RAID function.
USB 2x USB 2.0 (Rear)
4x USB 2.0 (Front)
4x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)
3x USB 10Gbps Type A (Rear)
1x USB 10Gbps Type C (Front)
1x USB 20Gbps Type C (Rear)
LAN Realtek® RTL8125B 2.5Gbps LAN
Internal IO 1x Power Connector(ATX_PWR)
2x Power Connector(CPU_PWR)
1x CPU Fan
1x Pump Fan
6x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Tuning Controller connector(JDASH)
2x Addressable V2 RGB LED connector (JARGB_V2)
2x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 5Gbps Type A ports
1x USB 10Gbps Type C ports
WIRELESS LAN & BLUETOOTH AMD Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX
Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands
Supports 802.11 a/ b/ g/ n/ ac/ ax

Supports Bluetooth® 5.3**

* The usage of Wi-Fi 6GHz band relies on Windows 11 support and depends on every country’s regulations.
** The Bluetooth version may be updated, please refer to the Wi-Fi chipset vendor’s website for details.
LED FEATURE 4x EZ Debug LED============================================
187223【【組裝價】微軟Windows 11 Home 家用中文隨機版 64位元-OEM序號-KUK-00003(I7/R7/16G/1TB)】
============================================
218142【威剛 ADATA DDR5-5600 16G】
============================================
220947【【組裝價】美光 Crucial E100 1TB/M.2 PCIe Gen4/讀:5000M/寫:4500M/QLC/五年保*捷元代理商公司貨】
============================================
210611【技嘉 Radeon RX 9070 XT GAMING 16G/三風扇/註冊五年保(長28.8cm)】
============================================
207300【曜越 Toughpower GX3 850W (80+金牌/ATX3.1/PCIe 5.1/直出/五年保固/越南製)】
型號
PS-TPD-0850NNFAGT-3
watts
850W
機種
TPS-0850AH2NLG-S
WATTS_spec
850W
顏色
Black
Dimension ( W / H / D )
150mm(W)x86mm(H)x140mm(D)
功率因素校正(PFC)
Active PFC
Power Good Signal
100-150 msec
Hold Up Time
> 17msec at 80% load
Input Current
15A-8A
Input Frequency Range
50Hz/60Hz
電壓
100-240V～
作業溫度
5°C to + 40°C
Operating Humidity
20% to 85%,non-condensing
Storage Temperature
-40°C to + 55°C
Storage Humidity
10% to 95%, non-condensing
散熱系統
12cm FDB Fan
Efficiency
Meet 80 PLUS® Gold at 115Vac input.
平均故障間隔時間
100,000 hrs minimum
Safety Approval
FCC/ICES/CB/cTUVus/S-mark
PCI-E 6+2pin
4
PCIe 12+4pin
1(450W)
保護項數
OVP/UVP/OCP/OPP/OTP/SCP============================================
220977【AMD Ryzen7 7800X3D Tray【8核16緒】(4.2GHz(Turbo 5.0GHz)/ZEN4/含內顯/無外盒/120W/代理商三年)】
名稱
AMD Ryzen™ 7 7800X3D
系列
Ryzen
系列
Ryzen 7000 Series
尺寸外型
桌上型電腦, 盒裝處理器
Market Segment
Enthusiast Desktop
AMD PRO 技術
否
區域供貨情況
全域
原代號
Raphael AM5
處理器架構
Zen 4
處理器核心數
8
多執行緒 (SMT)
是
執行緒數
16
最大超頻時脈
高達 5 GHz
基本時脈
4.2 GHz
L1 快取
512 KB
L2 快取
8 MB
L3 快取
96 MB
預設 TDP
120W
處理器核心適用的處理器技術
TSMC 5nm FinFET
I/O 裸晶的處理器技術
TSMC 6nm FinFET
處理器運算裸晶 (CCD) 大小
71mm²
I/O 裸晶 (IOD) 大小
122mm²
封裝裸晶數
2
AMD EXPO™ 記憶體超頻技術
是
超強精準頻率提升
是
曲線最佳化工具電壓偏移
是
AMD Ryzen™ Master Support
是
處理器插槽
AM5
Supporting Chipsets
A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850
CPU Boost Technology
Precision Boost 2
指令集
x86-64
支援的延伸指令集
AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
散熱解決方案 (PIB)
未隨附
Recommended Cooler
Liquid cooler recommended for optimal performance
最高工作溫度 (Tjmax)
89°C
推出日期
04/06/2023
*作業系統支援
Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
連線
Empty heading
Native USB 3.2 Gen 2 (10Gbps)
4
Native USB 3.2 Gen 1 (5Gbps)
0
Native USB 2.0 (480Mbps)
1
原生 SATA 連接埠
0
PCI Express® Version
PCIe® 5.0
原生 PCIe® 通道 (總共/可用)
28 , 24
Additional Usable PCIe Lanes from Motherboard
X670E 12x Gen4
X670 12x Gen4
B650E 8x Gen4
B650 8x Gen4
NVMe 支援
Boot , RAID0 , RAID1 , RAID10
系統記憶體類型
DDR5
記憶體通道數
2
最大記憶體
128 GB
系統記憶體子類型
UDIMM
最高記憶體速度
2x1R DDR5-5200
2x2R DDR5-5200
4x1R DDR5-3600
4x2R DDR5-3600
支援 ECC
Yes (Requires mobo support)
顯示卡功能
Empty heading
顯示卡型號
AMD Radeon™ Graphics
顯示卡核心計數
2
顯示卡頻率
2200 MHz
USB Type-C® DisplayPort™ 備用模式
是
