商品規格
190142【AMD Ryzen5 7500F MPK【6核12緒】(3.7GHz(Turbo 5.0GHz)/ZEN4/65W/無外盒/含散熱器/代理商三年)】
Name
AMD Ryzen™ 5 7500F
Family
Ryzen
Series
Ryzen 7000 Series
Form Factor
Desktops, Boxed Processor
Market Segment
Enthusiast Desktop
AMD PRO Technologies
No
Regional Availability
Global
Former Codename
Raphael AM5
Processor Architecture
Zen 4
# of CPU Cores
6
Multithreading (SMT)
Yes
# of Threads
12
Max. Boost Clock
Up to 5 GHz
Base Clock
3.7 GHz
L1 Cache
384 KB
L2 Cache
6 MB
L3 Cache
32 MB
Default TDP
65W
Processor Technology for CPU Cores
TSMC 5nm FinFET
Processor Technology for I/O Die
TSMC 6nm FinFET
CPU Compute Die (CCD) Size
71mm²
I/O Die (IOD) Size
122mm²
Package Die Count
2
Unlocked for Overclocking
Yes
AMD EXPO™ Memory Overclocking Technology
Yes
Precision Boost Overdrive
Yes
Curve Optimizer Voltage Offsets
Yes
AMD Ryzen™ Master Support
Yes
CPU Socket
AM5
Supporting Chipsets
A620 , X670E , X670 , B650E , B650 , X870E , X870 , B840 , B850
CPU Boost Technology
Precision Boost 2
Instruction Set
x86-64
Supported Extensions
AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
Thermal Solution (PIB)
AMD Wraith Stealth
Thermal Solution (MPK)
AMD Wraith Stealth
Max. Operating Temperature (Tjmax)
95°C
Launch Date
07/22/2023
*OS Support
Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit
Connectivity
Empty heading
Native USB 3.2 Gen 2 (10Gbps)
4
Native USB 3.2 Gen 1 (5Gbps)
0
Native USB 2.0 (480Mbps)
1
Native SATA Ports
0
PCI Express® Version
PCIe® 5.0
Native PCIe® Lanes (Total/Usable)
28 , 24
Additional Usable PCIe Lanes from Motherboard
X670E 12x Gen4
X670 12x Gen4
B650E 8x Gen4
B650 8x Gen4
A620 4x Gen3
NVMe Support
Boot , RAID0 , RAID1 , RAID10
System Memory Type
DDR5
Memory Channels
2
Max. Memory
128 GB
System Memory Subtype
UDIMM
Max Memory Speed
2x1R DDR5-5200
2x2R DDR5-5200
4x1R DDR5-3600
4x2R DDR5-3600
ECC Support
Yes (Requires mobo support)
Graphics Capabilities
Empty heading
Graphics Model
Discrete Graphics Card Required============================================
198041【SINYA C4U尊榮服務 (SINYA品牌桌機專屬/Windows終生免費重灌)】
============================================
212587【技嘉 RTX 5060 WINDFORCE OC 8G (std:2512MHz/雙風扇/註冊四年保/長19.9cm)】
============================================
218142【威剛 ADATA DDR5-5600 16G】
============================================
219555【技嘉 B650EM FORCE WIFI6E (M-ATX/1H1P/Realtek 2.5Gb/Wi-Fi 6E/註冊五年保) 8+2+2相供電】
============================================
226226【技嘉 P650G PG5 (80+金牌/ATX3.1/PCIe 5.1/主日系/直出/五年保固)】
============================================
187223【【組裝價】微軟Windows 11 Home 家用中文隨機版 64位元-OEM序號-KUK-00003(I7/R7/16G/1TB)】
============================================
194055【宏碁 acer Predator GM7 1TB/M.2 PCIe Gen4/讀:7200M/寫:6300M/TLC/五年保(單面設計)】
============================================
190049【技嘉 C301 GLASS V2 黑 玻璃透側機殼 (E-ATX/Type-C/內建風扇前3後1/顯卡400mm/塔散170mm)】
============================================
203793【利民 Assassin king 120 SE (5導管/12cm風扇*1/高148mm)】
技術規格 :
散熱器規格:
尺寸：長120mm ×寬46 mm × 高148 mm
重量：640克
熱管：6mm熱管×5支
散熱片: T = 0.4 mm；縫隙= 1.6 mm
TL-C12C V1.0 風扇規格:
尺寸：長120 mm × 寬120 mm × 高25 mm
重量：120克
風扇轉速：1550 RPM±10%(MAX)
風扇噪聲：25.6 dBA
風量：66.17 CFM(MAX)
風壓: 1.53mm H2O (MAX)
安倍： 0.2A
接頭類型:4Pin PWM
接頭軸承類型：S-FDB 軸承
